12 Volt/24V/90V 120W DC Gear Motor 90mm Metal Frame Smoothly Running Motor Product Description:Gear Motor-Torque Table Allowance Torque Unit:Upside (N.m)/Belowside (kgf.cm)•Gearhead and Intermediate gearhead are sold separately.•Enter the reduction ratio into the blank() within the model name.•The speed is

Featured Products

12 Volt/24V/90V 120W DC Gear Motor 90mm Metal Frame Smoothly Running Motor

12 Volt/24V/90V 120W DC Gear Motor 90mm Metal Frame Smoothly Running Motor
Product Description:

Gear Motor-Torque Table Allowance Torque Unit:Upside (N.m)/Belowside (kgf.cm)

•Gearhead and Intermediate gearhead are sold separately.
•Enter the reduction ratio into the blank() within the model name.
•The speed is calculated by dividing the motor's synchronous speed by the reduction ratio. The actual speed is 2%~20% less than the displayed value, depending on the size of the load.
•To reduce the speed beyond the reduction ratio in the following table, attach an intermediate gearhead (reduction ratio: 10) between the reducer and motor. In that case, the permissible torque is 20N.m.



Type

Motor/Gearhead

Gear Ratio

3

3.6

5

6

7.5

9

12.5

15

18

25

30

36

50

60

75

90

100

120

150

180

Speed

r/min

866

722

520

433

346

288

208

173

144

104

86

72

52

43

34

28

26

21

17

14

Z5D120-24GU-M(5GU180KB)

5GU()RC/

5GU()RT

0.87

1.04

1.45

1.74

2.41

5.44

4.02

4.82

5.78

8.03

9.64

10.4

14.5

17.4

20.0

20.0

20.0

20.0

20.0

20.0

8.87

10.6

14.8

17.7

24.6

55.5

41.0

48.2

59.0

81.9

98.3

106

148

177

200

200

200

200

200

200


Dimensions(Unit:mm):
