Note:
The specifications can be designed according to the customer's requirements!
Application:
Electric Drill, Screwdriver, Scanners, Printers, Vending Machine, Window Curtain, Coffee Machine, Electric Lock, etc.
Parameter:
About Us:
We specialized in researching, developing, and servicing electric motors, gearbox, and high precision gears with the small module. After years of development, we have an independent product design and R&D team, service team, and a professional quality control team. To realize our service concept better, provide high-quality products and excellent service, we have been committed to the core ability and training. We have a holding factory in Nanjing, which produces high precision small mold gears, gear shaft, gearbox, and planetary gearbox assembling.
Work-flow:
Certificate:
RoHS, CE, and more...
Service:
ODM & OEM
Gearbox design and development
Package&Ship:
Carton, pallet, or what you want
The delivery time is about 30-45 days.
Customer's Visiting:
FAQ:
1. Can you custom gearbox?
YES.
2. DO you provide the sample?
YES.
3. Do you provide technical support?
YES
4. Do you have a factory?
Yes, we are a professional manufacturer.
5. Can I come to your company to visit?
YES
The specifications can be designed according to the customer's requirements!
Application:
Electric Drill, Screwdriver, Scanners, Printers, Vending Machine, Window Curtain, Coffee Machine, Electric Lock, etc.
Parameter:
| Reduction ratio | 1/5 | 1/14 | 1/19 | 1/27 | 1/35 | 1/51 | 1/71 | 1/100 | 1/139 | 1/189 | 1/264 | 1/516 | 1/721 | 1/939 | |
| 12V | Rated torque(Kg.cm) | 0.32 | 0.75 | 1.0 | 1.4 | 1.9 | 2.4 | 3.3 | 4.7 | 6.6 | 7.4 | 10 | 10 | 10 | 10 |
| Rated speed(rpm) | 1000 | 375 | 270 | 193 | 148 | 102 | 73 | 52 | 37.3 | 27.5 | 19.7 | 10.5 | 7.5 | 5.7 | |
| 24V | Rated torque(Kg.cm) | 0.38 | 0.9 | 1.2 | 1.7 | 2.3 | 2.8 | 4.0 | 5.6 | 7.8 | 8.8 | 10 | 10 | 10 | 10 |
| Rated speed(rpm) | 990 | 370 | 265 | 191 | 147 | 101 | 72 | 51.5 | 36.9 | 27.2 | 19.3 | 10.4 | 7.4 | 5.7 | |
| Rotation direction | CCW | ||||||||||||||
| Length(L-mm) | 24.5 | 30.9 | 37.3 | 43.7 | |||||||||||
Rated volt(V) | Rated torque(g.cm) | Rated speed(rpm) | Rated current(mA) | No-load speed(rpm) | No load current(mA) | Weight(g) |
| 12 | 79 | 5200 | <=500 | 6000 | <=130 | 93 |
| 24 | 94 | 5140 | <=300 | 6000 | <=80 | 91 |
About Us:
We specialized in researching, developing, and servicing electric motors, gearbox, and high precision gears with the small module. After years of development, we have an independent product design and R&D team, service team, and a professional quality control team. To realize our service concept better, provide high-quality products and excellent service, we have been committed to the core ability and training. We have a holding factory in Nanjing, which produces high precision small mold gears, gear shaft, gearbox, and planetary gearbox assembling.
Work-flow:
Certificate:
RoHS, CE, and more...
Service:
ODM & OEM
Gearbox design and development
Package&Ship:
Carton, pallet, or what you want
The delivery time is about 30-45 days.
Customer's Visiting:
FAQ:
1. Can you custom gearbox?
YES.
2. DO you provide the sample?
YES.
3. Do you provide technical support?
YES
4. Do you have a factory?
Yes, we are a professional manufacturer.
5. Can I come to your company to visit?
YES
