57mm-BLDC-motor


57mm Jk57bls 36V 4000rpm Inrunner Brushless DC Motor 3D Printed Brushless DC Motor

Specification:

General Specification
(Item)(Specification)
Winding typeStar
Hall effect angle120 120 degree electrical angle
Shaft run out0.025mm
Radial play0.02mm@450g
End play0.08mm@450g
Max.radial force75N @20mm form the flange
Max.axial force15N
Insulation classClass B
Dielectric strength500VDC for one minute
Insulation resistance100MΩ Min.,500VDC

Electrical Specification
SpecificationUnitJK57BLS005JK57BLS01JK57BLS02JK57BLS03JK57BLS04
Number Of PhasePhase3
Number Of PolesPoles4
Rated VoltageVDC36
Rated SpeedRpm4000
Rated TorqueN.m0.0550.110.220.330.44
Rated CurrentAmps1.223.65.36.8
Rated PowerW234692138184
Peak TorqueN.m0.160.330.6611.32
Peak CurrentAmps3.56.811.515.520.5
Back E.M.FV/Krpm7.87.77.47.37.1
Torque ConstantN.m/A0.0740.0730.070.070.068
Rotor Inertiag.c3075119173230
Body Lengthmm37476787107
WeightKg0.330.440.7511.25
Sensor/Honeywell
Insulation ClassB
Degree of ProtectionIP30
Storage Temperature-25~+70ºC
Operating Temperature-15~+50ºC
Working Humidity85% RH

Drawing:

57mm Jk57bls 36V 4000rpm Inrunner Brushless DC Motor 3D Printed Brushless DC Motor


57mm Jk57bls 36V 4000rpm Inrunner Brushless DC Motor 3D Printed Brushless DC Motor



Company Profile:

         CHANGZHOU JKONGMOTOR CO.,LTD (Changzhou Jingkong Motor&Electric Appliance Co.,Ltd)is an ISO9001 Professional
manufacturer. Was established in 2011 year. We are a professional manufacturer in Changzhou city, China. Production Capacity
exceeds more than 1million motors per year.
            Our Company offers three major series of products: Hybrid Stepper motors, Brushless Dc motor and Dc Brush motor.
We are always continues develop new type models.We are also have several joint venture companies who specialized in the
production of AC servo motor, PM stepper motors, Spindlemotor and Motor drivers. We export our motors to more than 30
countries Such as United States, Germany, Russia, Turkey, Brazil and so on.
           Jkongmotor sold to major manufacturing Companies for Industry of automation, medical and health care equipment,
3d printermachines, packing devices, Information Technology, household appliance products.
We have an Engineering team
with many years of experience in application Engineering, design Engineering with the latest advances equipment. Our
Engineering Staff provides the finest quality product with service after the product is delivered to our Customers.
